Instrumentation & Monitoring for the E330 Downtown Bellevue Tunnel

0
angled borehole at E330 Downtown Bellevue Tunnel

Drilling angled borehole for inclinometer. All boreholes were started by vacuum excavation to ensure that no unmarked utilities were present.

The E330 Downtown Bellevue Tunnel project is owned by Sound Transit, the regional authority for mass transit in the Seattle metropolitan area. The tunnel is part of Sound Transit’s East Link Light Rail Extension, slated to be in service in 2023.

The 2,000-ft tunnel would be mined through over-consolidated, Pre-Vashon glacial till that was above the water table. Much of the tunnel would pass directly under 110th Ave NW, a tree-lined, north-south thoroughfare with multi-story residential and commercial structures on either side. The width and height of the tunnel (36 x 32 ft) would put these structures, utilities, and the avenue itself within the zone of influence, so a robust instrumentation program was prescribed by the designers. Geo-Instruments was selected by the GC to supply, monitor and maintain the instruments.

The original design for the SEM tunnel specified a 6-heading method of excavation. The GC proposed excavating in 3 full-width headings for the south half of the tunnel, where soils were known to be competent. Sound Transit accepted the proposal but required additional instrumentation for monitoring the primary tunnel liner and ground settlement.

Downtown Bellevue Tunnel map

Figure 1: Sound Transit project map. The 2000 feet of tunneling started at the East Main location and ended at the Bellevue Downtown location.

Scope of Instrumentation

The instrumentation program included monitoring of possible deformation of the soil-nail walls at the south portal, water levels along the tunnel alignment, lateral deformation on either side of the tunnel, settlement of the road surface and underground utilities, deformation of an abutting wall of a multi-level, below-ground parking garage, and loads on the lattice girders in the tunnel liner. An instrumentation data management system was to display measurements graphically, send alerts of exceedances, and generate daily reports.

Implementation of the Program

Instruments included piezometers, inclinometers, extensometers, AMTS, tiltmeters, laser distance meters and strain gauges. Instruments were arranged in arrays that aligned borehole instruments, surface settlement points, and tunnel strain gages at approximately the same stationing. Wireless data collection was used as much as possible.

/**** Advertisement ****/

Piezometers

Piezometers were installed along the tunnel alignment collocated with observation wells and inclinometers at 10 locations. All were automated with dataloggers and wireless communications. Groundwater levels did not fluctuate much in the dense till, but some instruments detected draining of perched water by probe drilling ahead of the excavation.

Inclinometers

Inclinometers were installed on each side of the tunnel alignment at 22 locations. Boreholes were drilled vertically to a depth 10 ft below the tunnel invert and passed 3 ft from the tunnel springline. Design depths varied between 63 and 106 ft.

In two locations permission to drill from private property was not forthcoming and drilling vertically from the City’s right of way would have placed the inclinometers inside the tunnel envelope. This issue was resolved by drilling from the right-of-way at angles of about 4 degrees. Subsequent inclinometer surveys confirmed that both inclinometers were within 1 in. of their intended placement.

Inclinometers were the only instruments that were monitored manually. The maximum reading rate was only once per day, which did not justify automated readings.

Inclinometer surveys showed lateral displacements starting just before or right after the tunnel heading reached the instrument. In two instances, displacements exceeded the 0.2-in. alarm threshold, but never the 0.3-in. limit.

Extensometers

Multipoint borehole extensometers were specified to monitor possible settlements above the tunnel centerline. The 16 extensometers would be installed at 100-ft intervals for the south half of the tunnel and then at 200-ft intervals for the north half. Depths ranged from 10 to 46 ft, with the deepest anchors of each extensometer placed 3 ft from the tunnel crown. An 8-in. measurement range along with the capability of manual checks was required for each anchor.

The extensometers had to be installed in the roadway. To avoid obstructing traffic, they had to be completely below grade. The instruments also had to be automated, which would normally involve trenching for power and signal cables and installation of curbside dataloggers.

Geo-Instruments was able to offer a trenchless, wireless solution by custom building extensometers with self-powered, waterproof heads that incorporated compact, temperature-stable 4-20 mA sensors, dataloggers, and cellular modems. Measurement signals were transmitted wirelessly via the company’s flush-mount, LidLink traffic-rated antennas.

No significant settlements were detected by the extensometers, although one extensometer reported about 0.2 in. of movement at its bottom anchor, which was installed in a less stable sand lens.

AMTS – Automated Motorized Total Stations

AMTS were installed at 12 locations to monitor 350 prisms on the roads and structures along the tunnel alignment. Road prisms, serving as surface settlement points, were installed at 50-ft intervals in arrays of 5 that crossed the road. L-Bar Mini-prisms were installed on structural elements and corners of buildings to detect any movements of the buildings.

AMTS Pedestals

AMTS require unobstructed views of prisms in order to make measurements. This presented a challenge for the south half of the alignment, where trees and foliage blocked lines of sight from preferred mounting locations. After considering many configurations, the team installed the AMTS units on relatively low steel pedestals, positioning them with deliberate precision to maintain lines of sight to all monitored prisms.

The north half of the alignment had fewer obstructed lines of sight, so positioning the AMTS units was much easier. In fact, the City allowed Geo-Instruments to mount AMTS units on concrete light poles. The poles had built-in threaded sockets that were used to mount the AMTS brackets and dataloggers, and as a bonus, they were also equipped with 120v AC outlets that the City energized for Geo-Instruments to use. From an instrumentation engineer’s perspective, life just does not get any better than this.

Measurements of the road prisms showed settlement started soon after the tunnel heading reached each array but stabilized 10 to 20 days afterward. As expected, settlements were larger above the tunnel centerline and much smaller at the edges of the zone of influence. Values were in the range of 0.1 to 0.25 in., which was below the threshold and limit values set at 0.3 and 0.45 in. As the tunnel surfaced at the north end of the project, settlements up to 0.55 in. were reported, still below the threshold and limit values set at 0.65 and 0.95 in.

Measurements of prisms mounted on buildings showed no significant movements.

Separate dataloggers were dedicated to each instrumented lattice girder ring. Strain readings were transmitted to a base station at the tunnel portal by radio.

Skyline Building Parking Garage

The Skyline Building is a 23-story office tower with a multi-level, basement parking garage that was built out to the property line. Because the tunnel excavation would eventually pass within 3 ft, the east wall of the garage was reinforced on three levels with a rebar mat, 6 in. of concrete and additional stiffening on two levels with steel struts across a ventilation shaft.

Instrumentation included strain gauges on the rebar mats, in the concrete, and on the reinforcing struts. Other instruments were installed on the same gridlines. These included displacement gauges, laser extensometers to monitor wall-to-stable core distances, and vertical arrays of tiltmeters to monitor lateral deformation. All of the instruments were connected to dataloggers, and measurement signals were transmitted wirelessly through the ventilation shaft.

No movement or deformation was detected by the sensors in the parking garage. Total strains in the reinforcement of the east wall were insignificant fractions of the warning threshold values. Measurements from other sensors generally tracked changes in temperature.

In-Tunnel Instrumentation

The steel lattice girder supports of the SEM tunnel were spaced at 4-ft intervals and installed in sections as the mining sequence allowed. The sections were joined to form complete rings. Rings were instrumented every 50 ft of tunnel, with the exact interval varying slightly to align with the instrument arrays installed at the surface.

Each ring had 18 arc-weldable strain gauges. Top heading girders were prepared with 9 gauges, bench level girders with 3 gauges each, and invert girders with 3. The north half of the tunnel was mined in 6 headings, with the left side leading the right by 50 ft, so girders were prepared with 6 gauges in each top heading and 3 in each bench. The invert was not instrumented.

Gauges were arc-welded onto the bars of the girder, tested, and then wrapped with thick aluminum flashing for protection from high-velocity shotcrete. Cables were protected by conduit and tied to the protected side of the bars. A datalogger installed at each monitored ring obtained measurements and transmitted them via a short-haul radio to a base station installed at the south portal.

RELATED: Excavation Complete on Sound Transit’s East Link Bellevue Tunnel

Strain data revealed gradual increases in compression as ring thrust developed in the primary lining and confirmed the lattice girders performed as designed with no point loading conditions detected. A few transient changes in strain were attributed to accidental impacts from construction machinery.

Separate dataloggers were dedicated to each instrumented lattice girder ring. Strain readings were transmitted to a base station at the tunnel portal by radio.

Instrumentation Data Management System

All measurements, automated or manually read, were transmitted to Geo-Instruments web-based monitoring platform. Nearly 2,800 uniquely named sensors accounted for real and virtual (computational) sensors.

Baseline readings were recorded shortly after an instrument was installed. Afterwards, weekly readings were increased to daily with the approach of the tunnel heading and then decreased to weekly and monthly as the heading passed. The reading rate for the tunnel strain gauges was specified at 6-hour intervals.

Taking advantage of automation, Geo-Instruments chose to read all of the instruments, except inclinometers, at shorter intervals. This provided higher resolution for trend plots and earlier notification of any alarm conditions.

The project website displayed sensor locations, values, and alarm status on 125 plan views and section views. It also provided over 300 plots for data. Six separate reports were automatically generated and sent via email every day, each containing all the pertinent plots for a given coverage area of the project. There were nearly 50 users accessing the project website and reports daily.

Geo-Instruments created a virtual sensor to represent the current location of the tunnel heading. Negative values indicated the tunnel heading was approaching the instrument array and positive values indicated the tunnel heading had passed. The GC’s tunnel engineer updated the current heading location after each round of excavation. The virtual sensor was displayed on all plots, providing easy visualization that informed the interpretation of the data.

RELATED: Tunnel Achievement Award – Northgate Link Extension

Conclusion

The instrumentation and monitoring program for the E330 contract served its intended purpose. It helped mitigate risk by enhancing safety at the site for both tunnel workers and the public, and it provided data that validated both the original design by H-J-H and the 3-heading redesign proposed by the GC.

Automated monitoring and wireless data transmissions were key to the success of the program. These factors minimized interruptions of construction work, avoided obstructing daily traffic, and provided cost-effective and timely high-quality data that could not be duplicated with manual monitoring.

The Project Team

Geo-Instruments, (Geotechnical Instrumentation Specialist) worked closely with the project team, including Atkinson Construction (General Contractor), Gall Zeidler Consultants (Tunnel Engineer), Sound Transit (Owner), McMillen Jacobs Associates (Construction Management), Hatch Mott MacDonald/Jacobs Engineering/HNTB (Design Team), Holt Services (Geotechnical Drilling), Yonemitsu Geological Services (Geologist), Kilroy Realty (Skyline Building Management) and the City of Bellevue.
