TERRATEC Delivers Two More EPBMs for Istanbul Metro

By TBM News December 20, 2016

The new machines will be used on the $1.45 billion US) Dudullu-Bostancı Metro Line project,

TERRATEC announced the delivery of a further two 6.56-m diameter earth pressure balance (EPB) tunnel boring machines for the ongoing expansion of the Istanbul Metro system in Turkey. The announcement came following a factory acceptance test on Dec. 6.

The new machines will be used by the Şenbay Madencilik-Kolin-Kalyon Joint Venture ¬– along with two other TBMs – on the €1.4 billion ($1.45 billion US) Dudullu-Bostancı Metro Line project, which runs north to south across the densely populated Anatolian side of the city. The 14.2-km long line, along with its 13 new stations, will be located entirely underground.

Members of the JV were so impressed with the performance of the TERRATEC machine (S42) used on the new Mecidiyeköy-Mahmutbey Metro line – which is currently being built by the Gülermak, Kolin and Kalyon JV – that they were very keen to employ a further two machines, S50 and S51, on their second project for the Istanbul Metropolitan Municipality (IMM).

The customized TERRATEC TBMs have versatile mixed-face cutterheads with an opening ratio of about 35%, designed to manage Istanbul’s geology – which includes both rock and soil formations – and state-of-the-art features such as VFD electric cutterhead drives, soft ground cutting tools that are interchangeable with 17-in. roller disc cutters, high torque screw conveyors, and active articulation systems. The tunnel linings will consist of reinforced concrete trapezoidal segments (5+1), with an outer diameter of 6,300 mm, an inner diameter of 5,700 mm and a width of 1,400 mm.

“I was very impressed by the TERRATEC machines when I attended the recent factory inspection and I am looking forward to great production records being set by the TBMs,” said Feriha Mert, Anatolian Rail Systems Manager, for the IMM.

The fully automated Dudullu-Bostancı Metro Line (GoA4) – with driverless trains, CBTC, and platform screen doors at stations – will provide numerous connections to other Istanbul transportation systems, such as the Bosphorus ferry (at Bostancı Harbour), the Marmaray railway, the Kadıköy-Kartal metro line and the Üsküdar-Çekmeköy metro line.

Tunneling is expected to commence in early 2017 and be completed by mid-2019.
